Dimensions B and D are referenced to the base plate schedule for sizing requirements. Dimensions C and D apply only as specified in the corresponding schedule.
DIMENSION "B" DIM. "D" DIM. "D" REFER TO BASE PLATE SCHEDULE FOR DIMENSIONS. DIMENSIONS C & D APPLY ONLY IF SCHEDULE
