Structural · S-MVX2S

Roof Deck and Framing Connection at Steel Column

About this detail

Roof deck and framing members bear on a structural steel column aligned with a grid line. Roof deck and framing sizes are sized per plan. Beams connect to the column with shear tab connections.

GRID BM PER PLAN RF DK PER PLAN BM PER PLAN COL PER PLAN

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
