This exterior wall assembly features six-inch cold-formed metal framing finished on the interior with one-half-inch gypsum wall board. The exterior side is sheathed with five-inch gypsum sheathing protected by a fluid-applied air and weather-resistive barrier. An adhesive and drainage plane layer secures exterior mineral wool board insulation and thermally improved insulation board fasteners. The exterior finish consists of an EIFS base coat and finish coat incorporating a vertical control joint.
EXTERIOR ASSEMBLY U-FACTOR: U-0.071 MAX. 6" INTERIOR EXTERIOR MINERAL WOOL BOARD INSULATION FLUID-APPLIED AIR AND WEATHER RESISTIVE BARRIER FINISH COAT AND BASE COAT (EIFS) ADHESIVE AND DRAINAGE PLANE CONTROL JOINT THERMALLY IMPROVED INSULATION BOARD FASTENER 5/8" GYPSUM SHEATHING 1/2" GYPSUM WALL BOARD COLD FORMED METAL FRAMING 6"
