A structural steel beam frames into a column using top and bottom gusset plates secured with slip-critical bolts. Plates are sized per typical column flange or web conditions. Complete joint penetration welds are specified at the top and bottom with fillet welds on three sides.
PL PER "TYP BF COL FLG CONDITION" OR "TYP BF COL WEB CONDITION", T&B GUSSET PL CONN PL & SLIP CRITICAL BOLTS, SEE NOTE 3 BM PER BF EL 1 1/2" 12" 1 1/2" 3" OC 2" 2" 3/4" DC, CJP T&B 2 5/8" 2 5/8" 3" 2" MIN 2" MIN (3) SIDES P BOLTED CONNECTION
