A concrete slab with metal deck bears on a reinforced concrete coupling beam with slab reinforcement spaced per plan and one and three-eighths inches of clearance. Number five form saver dowels feature ninety-degree standard hooks with spacing per the slab plan at nine inches on center maximum. Number five by five-foot dowels are threaded on one end with spacing per the slab plan at nine inches on center maximum. The concrete surface is roughened to one-quarter inch amplitude at the connection per the coupling beam and wall elevations.
1 3/ 8" 14" CLR. #5 FORM SAVER W/ 90° STD HOOK W/ SPACING PER SLAB PLAN - 9" O.C. MAX. #5x5'-0" DWL W/ SPACING PER SLAB PLAN - 9" O.C. MAX. - THREAD ONE END SLAB REINF. PER PLAN TEXT ROUGHEN SURFACE TO 1/4" AMPLITUDE CONN. PER COUPLING BM SEE WALL EL.'S 6 S51-00 1 3/ 8" 14" CLR. MTL DECK - SPAN DIRECTION VARIES SLAB REINF. PER PLAN TEXT
