600S162-33 cold-formed steel roof joists at 24 inches on center bear on a shear wall of 362S162-33 studs and 362T162-33 tracks. 54-mil bent plate blocking with 3-inch top and bottom flanges installs between joists, secured with number 10 screws at 6 inches on center. Joists attach to the supporting wall assembly with number 10 screws at 6 inches on center. Shear wall framing per plan requires the track connected to studs with two number 10 screws at each stud location.
