An hollow structural section stub is welded to a wide flange beam sized per plan with a one-half by eight by zero-foot-eight plate and tied into a concrete slab by others. The hollow structural section stub matches the stair post above. Fillet welds of one-quarter inch are applied typically at the connection joints.
CONC SLAB BY OTHERS HSS STUB TO MATCH POST ABOVE WITH PL 1/2x8x0'-8" WELDED TO WF-BM WF BEAM SEE PLAN TYP 1/4 TYP 1/4 2
