Structural · S-MS8MH

Skewed Beam to Beam Bolted Connection

Elements

Connections

About this detail

A skewed beam-to-beam connection frames into a supporting beam web. The supported beam incorporates a top flange cope with a maximum length of two and one-half inches and a minimum one-half inch clearance to the beam cope. Three-quarter inch bolts and connection plates fasten the members per general structural notes. Edge distances and spacing dimensions govern the fastener layout relative to the web centerline and the face of the web.

Members view this detail in full resolution, download the CAD files (SVG, PDF), and can adapt it in the built-in CAD editor — export DXF, DWG, or PDF.
