Structural steel beams per plan carry vertical and horizontal angle members sized as L4x4x1/4, tying hollow structural section soffit framing into structural steel framing and exterior wall girts. Connection plates measuring 3/8 inch by 3x0'-6 1/2 inches and 3/8 inch by 5 1/2x0'-6 1/2 inches secure the framing using two 3/4 inch diameter A325-SC-OVS bolts spaced at 3 inches on center. Welds including one-quarter inch fillet welds and complete joint penetration welds are specified at structural junctions. Wall panels, soffit panels, and a hangar door interface are coordinated with architectural drawings.
A B GIRT PER EL TYP BOS EL 165'-2" PL3/8X3X0'-6 1/2" W/ (2) 3/4" DIA A325-SC-OVS BOLTS AT 3" OC TYP L4X4 PER NOTE 8/S-160 S-160 1/4 1/4 TYP 1/4 3 NS&FS TYP CJP UT HSS SOFFIT FRMG PER PLAN TYP 2'-10" 1'-1 1/2" * 1'-10" * 4'-5 1/2" * 8'-7" * WALL PANEL PER ARCH DWG A-351 - A-353 1/4 2 1/2 L4X4X1/4 L4X4X1/4 L4X4X1/4 1/4 1/4 PL3/8X5 1/2X0'-6 1/2" W/ (2) 3/4" DIA A325-SC-OVS BOLTS AT 3" OC HANGAR DOOR PER ARCH DWG A-422 TYP SOFFIT PANEL PER ARCH DWG A-351 - A-353 L4X4X1/4 BM PER PLAN TYP
