A steel bottom chord connects to a wide-flange steel column using a shear plate with standard round holes. The connection is detailed with specified connections per sheet S5.01 or S5.01 at the wide-flange column where it occurs. The assembly repeats symmetrically on both sides of the column.
CONN. PER OR AT WF COLUMN WHERE OCCURS 1 S5.01 4 S5.01 STL BTM CHORD PROVIDE STD ROUND HOLES IN SHEAR & STL COL. OCCURS BOTHS SIDES AT SIM
