A wide flange beam connects to a hollow structural section column via a five-eighths inch by four inch shear plate. The plate is shop-welded to the column face with a three-sixteenths inch fillet weld. The beam web is field-bolted to the shear plate using a quantity of bolts designated as N. The connection provides a simple shear transfer between the beam and the column.
Text on the drawing
A A 5/16"x4" PL FOR BEAM CONN WELDED TO COL W/ "N" NUMBER OF BOLTS WF BEAM 3/16 ELEVATION SECTION A-A
