A wide flange steel beam frames into a hollow structural section steel column using connection plates sized per schedule A3/S402 and bolted with multiple rows of fasteners. A suspended concrete slab on metal deck sits above the framing assembly, with deck support details specified per structural notes and slab reinforcing sized per plan. The hollow structural section column passes continuously through the connection assembly with dimensions sized per plan.
DECK SUPPORT - SEE STRUCT. NOTES CONNECTION PL. - SEE SCHEDULE A3/S402 HSS COLUMN - SEE PLAN SUSPENDED CONC. SLAB - SEE PLAN FOR REINFORCING W BEAM - SEE PLAN
