An HSS member bears on a one-half-inch by five-inch bearing plate and is capped with a one-quarter-inch plate, secured with a one-quarter-inch seam weld to the HSS. The assembly connects to a wide flange column sized per schedule, utilizing five-sixteenth-inch fillet welds for the connection plates and HSS attachment.
1" 5/16 P.P. BEARING PL 1/2" x 5" CAP PL 1/4". SEAM WELD TO HSS. 5/16 1/4 W COL. PER SCHEDULE HSS PER PLAN 27 MM 5/16 5/16 HSS TO COL.
