A cold-formed steel cripple stud bears onto a header sized per schedule, secured with number eight sheet metal screws at each stud typically. A second detail view shows the header and jamb framing per elevation connected with fasteners. All framing components are joined using specified self-tapping sheet metal screws spaced twelve inches on center.
JAMB PER ELEVATION HEADER PER ELEVATION G CRIPPLE STUD HEADER PER SCHED #8 SMS @ EA STUD TYP #8 SMS @ 12" OC CTR
