A one-eighth-inch saw cut is formed in the top of the concrete slab and filled with gray flexible polyurethane joint sealant. The cut depth is specified as one-quarter of the slab thickness for wet cut saws or one inch to one and one-half inches for early-entry saws. Fifty percent of the reinforcing bars extend continuously across the control joint. The assembly rests over standard under slab preparation and subgrade layers.
UNDER SLAB PREPARATION SAW CUT JOINT 1/8" SAWCUT FILL w/ GRAY FLEXIBLE POLYURETHANE JOINT SEALANT 1/8" TYP. SIDES OF JOINT 4" TYP. BOTH REF. PLAN "T" T/4 FOR WET CUT SAW 1" TO 1 1/2" FOR EARLY-ENTRY SAW NOTE: REF. 5/S5.1 FOR ADDITIONAL INFORMATION. EXTEND 50% BARS ACROSS JOINTS TYP. CONTROL
