Drainage configurations for a concrete retaining wall with two alternatives for backfill and geotextile installation. Option A features a four-inch diameter perforated pipe conforming to ASTM test method 2729 surrounded by crushed rock wrapped in Mirafi 140N or equivalent filter fabric, topped with compacted impervious soil. Option B utilizes a four-inch diameter perforated pipe in Class II permeable material with a Miradrain or approved equal drainage mat. Both options require the perforated pipe to be laid with holes down and sloped to drain.
1' - 0" 0" @ INT. 18" @ EXT. CRUSHED ROCK - SEE SOILS REPORT MIRAFI 140N OR EQUIVALENT FILTER FABRIC - SEE SOILS REPORT COMPACTED IMPERVIOUS SOIL - SEE SOILS REPORT 4-INCH DIAMETER PERFORATED PIPE CONFORMING TO ASTM TEST METHOD 2729 - SEE SOILS REPORT NOTE: PERFORATED PIPE SHALL BE LAID WITH HOLES DOWN AND SLOPED TO DRAIN 1' - 0" 0" @ INT. 18" @ EXT. CLASS II PERMEABLE MATERIAL - SEE SOILS REPORT MIRADRAIN OR APPROVED EQUAL - SEE SOILS REPORT 4-INCH DIAMETER PERFORATED PIPE CONFORMING TO ASTM TEST METHOD 2729 - SEE SOILS REPORT OPTION A SEE SOILS REPORT OPTION B SEE SOILS REPORT
