This plan detail shows a square hollow structural section column centered on a base plate with four anchor rods positioned at the corners. Edge distances vary based on anchor rod diameter, requiring two and one half inches for rods up to one and one half inches in diameter, three and one half inches for rods up to two inches in diameter, and four inches for rods up to two and one half inches in diameter. Symmetrical dimensions are marked equal on both centerlines of the column.
CL COLUMN CL COLUMN B EQ EQ N EQ EQ 0' - 5" 2 1/2" FOR UP TO 1 1/2" DIA ROD 3 1/2" FOR UP TO 2" DIA ROD 4" FOR UP TO 2 1/2" DIA ROD D ROUND OR RECTANGULAR HSS PLAN
