This bridge section details the connection between precast concrete slabs over structural metal deck supported by structural steel bridge beams and steel angles. The Level 2 datum is established at twenty-one feet and zero inches. The precast concrete elements connect to the steel beams by others as noted. Steel angles and edge beam stiffeners provide support as indicated in the typical details.
201 LEVEL 2 21' - 0" SOSD SEE "TYPICAL STEEL EDGE BEAM STIFFENER" DETAIL TYP PRECAST CONCRETE, SEE NOTE 1 STL L STL BM STL BRIDGE BM NOTES: 1. CONNECTION FROM PRECAST TO STEEL BEAMS BY OTHERS. 2. SEE "TYPICAL STEEL BEAM CONNECTION" FOR SHEAR TAB AND BOLT INFORMATION. 14 S-F01
