A structural steel column base plate plan details an eight-anchor-rod configuration arranged symmetrically around the column profile. Anchor rods include washers and are positioned with typical edge distances. A one-inch diameter grout hole is provided at the contractor's option near the center. Welds at the column flanges and web are specified with complete joint penetration welds.
EQ EQ "W" EQ EQ "L" PLAN BASE PL AR W/ WASHER PL "A" 1"ø GROUT HOLE AT CONTR OPT CJP EA FLG, DC CJP WEB, DC FOR PL "B" BELOW "N" FOR PL "M" "B" BELOW TYP 1" TYP 8" (8) AR CONFIGURATION
