A buckling-restrained braced frame connection features diagonal braces tied into gusset plates at the base and beam intersections. Hatching indicates the extent of the protected zone typical to the assembly. A three-inch typical dimension marks spacing along the structural members.
525SD007 DETAIL BRBF BASE PLATE HATCHING INDICATES EXTENT OF PROTECTED ZONE TYPICAL 3" TYP NOTES: - - S4.2 3
