This structural detail shows a concrete ramp transition slab poured over expanded polystyrene fill on top of a base slab or deck with fill. The new concrete slab connects to the substrate using number three adhesive anchors with a four-inch embedment spaced at twelve inches on center each way, requiring a pull test to 4,200 pounds at the perimeter. Where the depth of the new concrete reaches six inches maximum, the joint is roughened with a one-quarter-inch amplitude. The assembly includes a blocked-out depress and scratch finish at the termination point with a two-and-one-half-inch minimum thickness tapering to a one-inch minimum.
12" 6" MAX 2 1/2" MIN 1" MIN SLOPE SEE ARCH SLAB OR DECK W/ FILL #3 ADHESIVE ANCHOR W/ 4" EMBED @ 12" OC EW. PULL TEST TO 4200 LBS AT PERIMETER. BLOCK OUT DEPRESS & SCRATCH FINISH SLAB 1/4" AMPLITUDE ROUGHENED JOINT WHERE DEPTH OF (N) CONCRETE REACHES 6", POUR SLAB OVER EPS FILL @ RAMP TRANSITION LTS EQ EQ
