A structural connection joins a steel girder and a concrete return panel. A hollow structural section member occurs at the wall and is supported by a seven-eighths-inch thick plate sized per the girder manufacturer. A horizontal slotted ledger connects the assembly to the concrete panel, while metal deck and hollow structural section blocking tie into the framing per plan. A one-quarter-inch fillet weld with a three-inch minimum length secures the components, subject to joist manufacturer verification.
NOTE: SEE 7/S5.51 FOR REMAINING INFO HSS BLKG PER 13/S5.82, HORIZ SLOTTED LEDGER PER 18/S5.83. SEE PLANS FOR EXTENT 3" MIN 1/4 VERIFY W/ JOIST MFR METAL DECK PER PLAN HORIZ SLOTTED LEDGER PER 18/S5.83 GIRDER PER PLAN PL 7/8"x (AS REQ'D BY GIRDER MFR) HSS PER PLAN AS OCCURS, ATTACH TO COLUMN PER 7/S5.51, AT WALL PROVIDE END PL & ATTACH TO CONC PANEL PER 18/S5.83 MAX 11 3/4"
