A three-eighths-inch thick gusset plate connects a hollow structural section brace to a hollow structural section column and hollow structural section beam at a common work point. The brace is welded to the gusset plate with five-sixteenths-inch fillet welds on both sides. A one-eighth-inch cap plate is seal welded at the top of the column. A note references detail 8/S6.06 for additional information not shown.
5/16 6 5/16 6 HSS BEAM REF. ELEVATION HSS BRACE REF. ELEVATION W.P. 1/8" CAP PL SEAL WELDED 5/16 5/16 HSS COL. REF. ELEVATION NOTE: REF. DETAIL 8/S6.06 FOR ADDITIONAL INFORMATION NOT SHOWN. GUSSET 3/8" PL
