A chevron bracing arrangement connects to the underside of a steel beam through a gusset plate of specified thickness. The corebrace attaches via bolted lug connections on each brace member. Fillet welds secure the gusset plate assembly with typical sizes indicated on the drawing. A work point is established at one-half the nominal depth of the beam. Reference detail 1 for additional information.
NOTE: REFERENCE DETAIL 1 FOR ADDITIONAL INFORMATION. 516 TYP Lgb Lgc TYP W b W b L wb L wb 516 PL 12 " NS & FS OF GUSSET PL 12 " NS & FS WORK POINT AT 12 NOMINAL DEPTH OF BM GUSSET THICKNESS, t g
