An HSS hanger and an inclined HSS brace frame into a horizontal structural steel beam via a one-quarter-inch plate slotted through the hollow structural sections and centered on the members. A three-sixteenths-inch fillet weld secures the connection assemblies. Erection bolts are provided as required at the hanger and brace reference elevations with specified minimum clearances and dimensions. A stop plate is positioned at similar conditions.
1/4" PL SLOTTED THRU HSS (CENTERED ON HSS) HANGER REF. ELEVATION w/ ERECTION BOLT AS REQUIRED CL HANGER BRACE REF. ELEVATION w/ ERECTION BOLT AS REQUIRED (NOT AT SIM) CL BRACE CL BEAM W.P. 3/16 3/16 1/2" 1/2" 1/2" TYP. 3/4" MAX. MIN. 4" MIN. 1/4" MIN. 3" TYP. 1/2" 3/16 3/16 TYP. HANGER AND BRACE AT SIM. STOP PL
