This connection details a structural steel moment connection between two beams of unequal depths. The top and bottom flanges feature typical complete joint penetration welds. The webs are connected using bolted plates with four rows of bolts on each side of the vertical joint. A typical moment plan symbol is included to indicate the orientation and connection type.
CJP, TYP T&B FLGS CONNECTION PER ,TYP MOMENT PLAN SYMBOL 3A BM TO BM (UNEQUAL DEPTHS)
