Perimeter metal studs align vertically along the edge of a concrete-filled metal decking slab supported by a structural steel beam per plan. A rigid clip assembly for hung spandrel framing connects the metal stud to the edge of the slab using required fasteners. A continuous track with self-tapping metal screws on each side attaches at each stud location. Bracing as required provides additional structural support to the assembly.
EQ. EQ. EDGE OF SLAB VERIFY PER ARCH BEAM PER PLAN METAL STUD CONT TRACK W/ SMS EA. SIDE AT EA. STUD RIGID CLIP ASSEMBLY FOR HUNG SPANDREL FRAMING FASTENERS AS REQ'D CONCRETE FILLED METAL DECKING BRACING AS REQ'D
