The roof deck bears on the top flange of an edge beam, with orientation varying as required. A bent plate specified per the plate schedule sits on the beam flange with dimensions per the architectural plan and a minimum three-inch dimension. Size and length of welds are specified per the plate schedule, with welds connecting the bent plate to the structural steel member. The plate schedule provides columns for leg length in inches, plate thickness t in inches, and weld size and length.
SIZE AND LENGTH PER "PL SCHED" ROOF DECK, ORIENTATION VARIES BENT PL PER "PLATE SCHED" W/ DIM PER PLAN EDGE BM PLATE SCHEDULE L (INCH) PLATE THICKNESS "t" (INCH) 2" 6" - - 8" L DIM PER ARCH, 3" MIN WELD SIZE AND LENGTH -
