A continuous bent plate edge form sits over the top flange of a structural steel beam, with plate thickness sized per the overhang table. The metal deck bears on the steel beam with a one and a half inch minimum end bearing, positioned relative to the steel beam web. Where the deck is flush with the edge, a three-sixteenths inch fillet weld is specified at sixteen-inch intervals. Where the deck overhangs, a three-sixteenths inch fillet weld is specified at twelve-inch intervals. The continuous bent plate is welded to the assembly with a three-sixteenths inch fillet weld at twelve-inch intervals.
3/16 3-12 CONT. BENT PL - SEE TABLE FOR REQ'D. THICKNESS, 't' 'L' 't' ≤1'-0" ≤1'-6" ≤2'-0" 3/16" 1/4" 5/16" SEE ARCH. SEE ARCH. 'L' 3/16 3-12 WHERE OVERHANGS 2" MIN. 1 1/2" MIN. STEEL BEAM - SEE PLAN END/EDGE OF METAL DECK METAL DECK PER SCHEDULE - ORIENTATION VARIES 3/16 3-16 WHERE FLUSH
