A continuous L3x3x1/4 ledger angle is welded to a beam sized per plan with three-sixteenths inch fillet welds. The decking per plan bears on the ledger angle with a three-and-a-half-inch depth and a one-and-a-half-inch clearance above. The ledger is discontinued at platform framing connections.
BM PER PLAN L3x3x1/4xCONT LEDGER, DISCONTINUE AT PLATFORM FRAMING CONN DECK PER PLAN 3/16 3/16 4-12 4-12 3 1/2" 1 1/2"
