An embed plate measuring 1/2 inch by 9 inches by 1 foot 6 inches is anchored to the wall with six 3/4-inch diameter by 5-inch long headed studs spaced per the indicated dimensions. The layout requires coordination with elevator drawings for exact elevation and positioning.
2" 7" 7" 2" 2" 5" 2" EMBED PL1/2X9X1'-6" W/ (6) 3/4" DIA X 5" LONG HEADED STUDS NOTE: 1. FOR ELEVATION AND LOCATION OF EMBED PLATE, COORDINATE WITH ELEVATOR DRAWINGS.
