A structural steel beam connects to a column web or flange using top and bottom gusset plates secured by slip-critical bolts. The connection incorporates a plate configuration per typical beam-to-column flange or web conditions, with complete joint penetration welds top and bottom. Bolt spacing includes a three-inch on-center vertical pitch with one-and-a-half-inch edge distances and minimum two-inch clearances. The beam flange is detailed with a specific cut profile and weld preparation on three sides.
PL PER "TYP BF COL FLG CONDITION" OR "TYP BF COL WEB CONDITION", T&B GUSSET PL CONN PL & SLIP CRITICAL BOLTS, SEE NOTE 4 BM PER BF EL 1 1/2" 12" 1 1/2" 3" OC 2" 2" 3/4" DC, CJP T&B 2 5/8" 2 5/8" 3" 2" MIN 2" MIN (3) SIDES, SEE NOTE 5 P BOLTED CONNECTION SEE NOTE 3
