A steel beam frames into the web of a depressed girder utilizing a bolted shear plate connection. AISC standard horizontal short-slotted holes are provided in the connection plate. The shear plate and bolt configuration are sized per the structural schedule, with the number of bolts determined by the plan layout. The girder top flange features a depression per plan to accommodate the framing condition, maintaining minimum AISC clearance requirements.
3" 1 3/4" 2 1/2" 3/4" K+AISC MIN 3" TYP CL GIRDER BOLTS SEE SCHED FOR SHEAR PL AND SEE PLAN FOR PER PLAN DEPRESSION NUMBER OF BOLTS REQ'D AISC STANDARD HORIZ SHORT-SLOTTED HOLES IN CONNECTION PL 3 SIDES SEE SCHED
