A wide flange column and beam intersect with buckling restrained braces framing into gusset plates welded to the structural steel members. Gusset plates feature wrap-around weld ends with specified lengths and welds detailed on the drawing. The brace centerline intersects at the working point with centered pin connections. Additional connection details are referenced on sheet S4-101.
WP GUSSET t g CL COL FOR BEAM TO COLUMN CONN, SEE BUCKLING RESTRAINED BRACE, TYP CL OF BEAM WF COL SEE PLAN WF BM SEE PLAN 7 S4-101 W4 L4 W4 L4 W3 L3 W3 L3 WRAP AROUND END OF GUSSET L3 1" L1 NOTE: FOR INFO NOT SHOWN & NOTED SEE 11 S4-101
