A structural steel edge beam and steel bridge beam support a concrete slab on steel deck at Level 2, located at elevation 21 feet zero inches. Precast concrete units sit adjacent to the edge condition, referenced to specific typical edge beam stiffener and kicker brace details. Steel angles connect structural elements with bolted framing conditions.
201 LEVEL 2 21' - 0" SEE "TYPICAL STEEL EDGE BEAM STIFFENER" DETAIL, TYP PRECAST CONCRETE, SEE NOTE 1 STL L STL BM STL BRIDGE BM 8 S-F01 SLAB ON STL DECK NOTES: 1. SEE "TYPICAL BEAM KICKER BRACE". 2. SEE "TYPICAL STEEL EDGE BEAM STIFFENER". 3. SEE "TYPICAL DECK EDGE CONDITIONS". 3/4" = 1'-0" 2 EDGE BEAM WITH PRECAST UNIT
