A structural steel one-sided beam-to-beam moment connection features a shear tab welded to the supporting member and bolted to the supported beam web. A three-eighths-inch full height stiffener plate is welded to the web with one-quarter-inch fillet welds on three sides. Additional three-eighths-by-four-inch plates are provided on each side to match the beam flange width, secured with one-quarter-inch fillet welds on two sides. Weld backup plates are required but omitted for clarity.
MOMENT CONNECTION NOTES BEAM TO BEAM C (ONE SIDED CONNECTION) 1. SHEAR TAB (AT COLUMNS) THICKNESS = BEAM WEB THICKNESS + 1/4" UON. 2. SHEAR TAB WELDS: FILLET WELD SIZE = (t SHEAR TAB)/2 UON COMPETE PENETRATION WELD OPTIONAL. 3. FOR SHEAR TAB THICKNESS, NUMBER OF BOLTS AND SHEAR TAB WELDING SEE "NON-MOMENT BEAMS CONNECTION SCHEDULE". 4. WHERE DOUBLE ROW OF BOLTS IS REQUIRED, USE THE MAXIMUM NUMBER OF BOLTS POSSIBLE IN THE FIRST ROW, BALANCE IN THE SECOND ROW. 5. FILLET WELD BOTH SIDES OF SHEAR TAB FULL HEIGHT. 6. USE STANDARD HOLES (NO SLOTS). 7. SEE GENERAL NOTES AND SPECIFICATIONS FOR SPECIAL INSPECTION REQUIREMENTS. SHOWN ON PLAN THUS: NOTE: WELD BACKUP PLATES. NOT SHOWN FOR CLARITY NO & SIZE OF BOLTS (SEE NOTE 3) SHEAR TAB (SEE NOTE 3) 3/8" FULL HEIGHT STIFFENER PLATE PL 3/8"x4" MIN EA SIDE TO MATCH BEAM FLANGE WIDTH M EL (SEE PLAN) T.O. STEEL T&B SEE NOTE 3 1/4 3 SIDES 1/4 2 SIDES
