New gas cylinders are secured against a new concrete masonry unit wall using a dual-tier Unistrut framing arrangement. Vertical P1000 Unistrut channels attach directly to the masonry wall face. Horizontal P2544 Unistrut arms extend outward to brace the cylinders at 14 inches and 40 inches above the floor finish. The horizontal channels connect to the vertical Unistrut using Unistrut channel nuts with springs and hex head screws. The overall assembly height to the top of the cylinders is 51 inches.
26" 14" (N) CYLINDER (N) CMU WALL (N) TOC (N) P2544 UNISTRUT ATTACH TO P1000 W/ UNISTRUT CHANNEL NUT W/ SPRING & HEX HEAD SCREW (N) P2544 UNISTRUT (N) P1000 UNISTRUT 25 1 2" 51" (N) P1000 UNISTRUT
