An elevator guide rail attaches to a support bracket per manufacturer specifications with two inches of field adjustment. The assembly incorporates a quarter-inch by ten-inch by twenty-inch steel plate and typical quarter-inch by ten-inch side plates welded to a structural support column. Dimensions range from two and one-quarter inches minimum to four and three-quarters inches maximum with a one and three-quarter inch offset.
1 3/4" 1/4"x10"x20" PL 1/4"x10" SIDE PL, TYP. ELEVATOR GUIDERAIL ATTACH TO BRACKET PER MANUFACTURER - PER VENDOR 2" ADJUST IN FIELD 4 3/4" MAX. 2 1/4" MIN.
