An HSS 4x3 beam with a one-quarter-inch cap plate at both ends bears on a half-inch by six-inch by nine-inch plate welded to the top of an HSS 5x5 post. An HSS 4x4 member connects adjacent to the post per plan. The connection is welded on both sides as indicated.
BOTH SIDES HSS 4x4 SEE PLAN HSS4x3 W/ 1/4" CAP PL BOTH ENDS SEE PLAN T/STEEL SEE PLAN 3" CL BEAM & POST PL1/2x6x0'-9" HSS 5x5 POST SEE PLAN
