A fall protection tieback pedestal features a six-inch standard pipe post with a three-quarter-inch top plate to match the manufacturer's plate requirements. The post mounts to an intersecting structural steel beam sized per plan, with top-of-steel elevation established per plan and designed for a five-kip ultimate load maximum. Three-eighths-inch full-depth stiffener plates are welded to each side of the beam web using one-quarter-inch fillet welds on three sides. The post connects to the supporting beam with a one-half-inch plate, and the fall protection system connection to the post and base is provided by others.
STIFF PL 3/8 FULL DEPTH EA SIDE (VERIFY W/ ARCH) 1'-6" MAX FALL PROTECTION SYSTEMS CONN TO POST & BASE BY OTHERS PL 3/4 TO MATCH PL BY MFR 6"Ø STD PIPE 1/4 1/4 TYP (3) SIDES 1/2 T/STL PER PLAN INTERSECTING BEAM PER PLAN W/ CONN PER 17/S6.01 5K ULTIMATE LOAD MAX
