A structural steel column splice connection is centered on a symmetry line. A full-height stiffener or shear plate is provided on each side, sized per plan with a three-eighth inch minimum thickness. The connection is secured with a plate one-half inch larger than the width of both members, fastened using four three-quarter inch diameter A325SC bolts.
A - CL SYMM C DETAIL FULL HT STIFF OR SHEAR PLT EA. SIDE PER PLAN (3/8" MIN.) PL 1/2XLARGER WIDTH OF BOTH MEMBERS W/ (4)-3/4'' DIA A325SC BOLTS COLUMN HERE OCCURS, DENOTED AS CA ON PLANS
