A structural steel column connects to a steel base plate seated on one and one-half inches of non-shrink grout above a concrete footing. The column is welded to the base plate with a five-sixteenth-inch fillet weld, and the assembly is secured by anchor bolts embedded in the footing. A concrete blockout surrounds the column base within the surrounding concrete slab on grade.
CONCRETE SLAB ON GRADE, SEE PLAN STEEL BASE PLATE (SEE SCHEDULE) ON 1.1/2" NON-SHRINK GROUT 5/16 CONCRETE FOOTING, SEE PLAN AND SCHED STEEL COLUMN, SEE PLAN AND SCHEDULE CONCRETE BLOCKOUT
