Built-up structural steel shapes are assembled after cutting the weld access hole to clear the flange-to-web connection. Welds are executed along the internal intersections of the plates following the geometry specified by the dimensional callouts.
BUILT-UP SHAPES ASSEMBLED AFTER CUTTING THE WELD ACCESS HOLE. 7 3 3/8" 1 2 3 3/8" 2 1 3 3 7 3/8" 8 3/8" 2 3/8"
