A wide-flange beam connects to a wide-flange column web using a welded shear tab and bolted web connection. Top and bottom stiffener plates weld to the column web aligned with the beam flanges. A two-sided connection is provided where framing occurs on both sides of the column with a half-inch maximum clearance.
T.O.S. WF COL PER PLAN TAB ¯ PER 2/S5.01 OR 4/S5.01 WF BEAM PER PLAN, CTR ON COL ® STIFF PLATE PER SCHEDULE, TOP & BOTTOM PROVIDE TWO-SIDED CONNECTION WHERE OCCURS ½" MAX T.O.S. COL. WHERE OCCURS B TAB ¯ TO COL WEB
