An exterior concrete slab on grade bears on a concrete foundation wall featuring a continuous 38x89 millimeter keyway. The slab is reinforced with 15M dowels spaced at 600 millimeters on center. A separate interior or adjacent slab on grade is separated from the foundation wall by joint filler. The exterior slab thickness is dimensioned at 40 millimeters with a 300 millimeter offset dimension.
TYPE A EXTERIOR SLAB ON GRADE SEE PLAN 40 (1 1/2") 900 (3'- 0 ") 300 (12") 15M DOWELS @600 (2' - 0") 38x89 (1 1/2"x3 1/2") KEYWAY CONT SLAB ON GRADE SEE PLAN JOINT FILLER CONCRETE WALL, SEE PLAN
