A steel core plate features typical lug plates welded at each end with designated dimensional parameters for width, length, and thickness. The plan and elevation views detail the geometry of the steel core and the attached lug plates including pin connections at each terminus. Dimensional callouts govern the overall length, plate widths, and lug spacing.
L b L ysc W c W sc D wL TYP 10 - STEEL CORE LUG PLATE, TYP ELEVATION VIEW 9 - L p W L /2 L s W L STEEL CORE LUG PLATE, TYP H c t sc W L /2 6 TYPICAL CORE PLATE DETAIL SCALE: NTS PLAN VIEW 8 -
