A structural steel beam framing connection occurs adjacent to an exterior cold-formed steel stud wall. The assembly features a concrete slab over a metal deck supported by a steel beam, which connects to the framing with a continuous 1/4-inch by 5-inch plate. The exterior wall incorporates 6-inch by 18-gauge metal studs spaced at 16 inches on center with a top track of 6-inch by 16-gauge continuous metal track. Wall finishes and exact dimensions are coordinated with architectural drawings.
STEEL BEAM, SEE PLAN CONCRETE OVER METAL DECK, SEE PLAN METAL STUDS AT 16" O.C. 6"x18 GA (600S162-43) SEE ARCH FOR WALL FINISH TOP OF WINDOW 6"x16 GA (600T125-54) x CONT TRACK PROVIDE PL 1/4"x5"xCONT C5 S511 A2 S511 A1 S511 1 1/2" SEE ARCH >12"
