An elevator separator beam or guiderail support tube connects to the shaft structure with shim plates inserted as required for width adjustment. The connection incorporates a minimum six-inch dimension and relies on manufacturer specifications for the elevator connection assembly.
MIN 6" PER MFR ELEVATOR CONNECTION BY MFR SEPARATOR BEAM OR GUIDERAIL SUPPOT TUBE PER ELEVATION A A SHIM PLATE AS REQUIRED FOR WIDTH
