Wide-flange beams frame into wide-flange column flanges and webs using a welded shear plate and field erection bolts. Erection bolts are installed per the contractor as required, supplemented by field welds sized per schedule. Continuity plates are specified at one-half inch top and bottom for W21x and smaller beams, and five-eighths inch top and bottom for W24x and larger beams, welded to the column flange with five-sixteenths inch fillet welds typically.
tw1 tw1 SEE SCHED CL COL ERECTION BOLTS PER CONTRACTOR AS REQUIRED tw2 3/4" 2 1/2" SHEAR PL 3 1/2" CL COL CONTINUITY PL: 1/2" T&B FOR W21x AND SMALLER 5/8" T&B FOR W24x AND LARGER 5/16 5/16 PL TO COL FLANGE, TYP 3/4" tw1 tw1 SEE SCHED tw2 2 1/2" ERECTION BOLTS PER CONTRACTOR AS REQUIRED 3 1/2" 3A BEAM TO WF COLUMN FLANGE 3B BEAM TO WF COLUMN WEB
