Plywood sheathing panels are applied with the face grain oriented perpendicular to the tongue and groove decking below. Four-foot edges are staggered as shown, with long continuous edges and short staggered joints across the assembly. Panel edge nailing requires eight-penny nails at six inches on center, while field nailing is specified as eight-penny nails at twelve inches on center each way. All roof nailing must be inspected prior to the application of any roofing material.
PLAN FACE GRAIN APPLY PLYWOOD SHEATHING WITH FACE GRAIN PERPENDICULAR TO TONGUE AND GROOVE DECKING. STAGGER 4'-0" EDGES AS SHOWN. PANEL EDGE NAILING SHALL BE 8d NAILS @ 6" o.c. ALL ROOF NAILING SHALL BE INSPECTED BEFORE ANY ROOFING MATERIAL IS APPLIED. 1. 2. 3. NOTES: FIELD NAILING 8d @ 12" o.c. EACH WAY LONG CONT. EDGES SHORT STAGGERED EDGES TONGUE AND GROOVE DECKING BELOW PKG-2
